Chapter 2: Hardware Installation
34
Cooling fans may wear down eventually. Please refer to the steps below for replacing cooling fans. When
using a new cooling fan, simply reverse the steps to install the fan back onto the enclosure and the system.
1. Locate the cooling fans at the rear panel.
2. From the rear side of the fan, loosen the
screw that secures the fan connector.
3. Disconnect the fan connector.
4. Loosen the lock-screw that fixes the fan on
the rear panel and take out the worn fan.
