Lanner NCA-5710 - Installing System Memory

NCA-5710 User Manual
35
The motherboard supports 12 memory slots for DDR4 registered DIMM. JCPU0 requires at least 1 memory
module to boot and run from.
Total Slots
12 (6 slots per processor)
Number of Channels
6 (Channel 0~5, 1 DIMM per channel) per processor
Supported DIMM Capacity
4GB, 8GB, 16GB, 32GB
Memory Size
Maximum 384 GB RDIMM (32GB*12)
Memory Type
DDR4 1.2 V ECC RDIMM 2666/2400/2133 MHZ
Minimum DIMM Installed
JCPU0 requires at least 1 memory module to boot and run from.
JCPU0
JCPU1
JDDR0~JDDR9 are assigned to
JCPU0.
JDDR10~JDDR19 are assigned to
JCPU1.
