Lantronix SISPM1040-xxxx-L3 Install Guide
33855 Rev. A https://www.lantronix.com/ 25
Power Supply Pin Descriptions (25160)
Terminal Pin No. Assignment (TB1)
Pin No.
Assignment
1
FG
2
AC/N
3
AC/L
Terminal Pin No. Assignment (TB2)
Pin No.
Assignment
1,2
DC OUTPUT +V
3,4
DC OUTPUT -V
5,6
Relay Contact
7,8
NC
DC OK Relay Contact
Contact Close
PSU turns on / DC OK.
Contact Open
PSU turns off / DC Fail.
Contact Ratings (max.)
30V/1A resistive load.
