Lantronix xPico - Connection Settings - TCP

4: Configuration Using Web Manager
from the network to the device. The default is No.
At Time of Disconnect
Select Yes to clear the input buffer when the network
connection to or from the device is disconnected. The default
is No.
Flush Output Buffer (Network to Serial)
With Active Connect
Select Yes to clear the output buffer with a connection that is
initiated from the device to the network. The default is No.
With Passive Connect
Select Yes to clear the output buffer with a connection initiated
from the network to the device. The default is No.
At Time of Disconnect
Select Yes to clear the output buffer when the network
connection to or from the device is disconnected. The default
is No.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Connection Settings - TCP
To configure a channel’s TCP settings:
1. On the main menu, click Connection. The Connection Settings window for the
channel displays.
xPico User Guide 27
