10: Firmware Upgrades
Figure 10-1. TFTP Window
6. Click the Put button to transfer the file to the unit. The unit performs a power
reset after the firmware has been loaded and stored.
After the firmware has been loaded and stored, which takes approximately 8 seconds
to complete, the unit performs a power reset.
Using TFTP: Command Line Interface
To download new firmware from a computer:
1. Enter the following from a TFTP command line interface:
tftp –i <ip address> put <local filename> <destination file
name>
The following examples demonstrate the TFTP command sequence to download the
.rom file and the .cob file:
tftp –i 192.168.1.111 put xpico_6800 X6
tftp –i 192.168.1.111 put xpico_webm_1900.cob WEB1
xPico User Guide 68
