13
Warranty
Specifications
The Pro Shot Alpha laser transmitter is warranted for twenty four (24)
months from the date of new equipment purchase from an authorized
dealer. During the warranty period, Laser Reference or its authorized
service center will repair or replace, at Laser Reference’s sole discretion,
laser transmitters (except for transportation costs), if the product is found to
be defective in workmanship or materials. Maintaining the calibration of the
laser is not the responsibility of Laser Reference or its authorized service
centers. If service is needed, the product must be sent FREIGHT PREPAID
to the nearest authorized service center or to Laser Reference.
Range with R9 receiver ...............
Leveling Accuracy ........................
Leveling Technology ....................
Self-Leveling Range ....................
Slope Matching Range ................
Height Alert ..................................
Rotation Coverage • Speed ..........
Machine Control Compatible .......
Warranty ......................................
Power Supply ...............................
Run Time .....................................
Automatic Shut-off .......................
Environmental ..............................
Laser Rating ................................
Laser beam type / power .............
Operating Temperature ................
2000’ diameter (610m dia.)
±10 arc sec.
(.060”@100’) (1.5mm@30m)
Servo Motor
±5 degrees
Single Axis, X Axis Self Levels, 8%
Normally Active, can be disabled
360º • 600, 1200 rpm (nominal)
Yes
24 Months Defects Coverage
4 C Alkaline or NiMH rechargeable
115 Hours (Alkaline), 65 Hours (NiMH)
12 Minutes Out of Level
Dust & water resistant (IP56)
CDRH Class II, IEC Class 2
Visible 670nm / <1mW
-20ºc to +60ºc (-4ºf to +140ºf)
