Laser 5091 Code Reader User’s Guide
42
Laser 5091 Code Reader User’s Guide
43
9 Printing & Update (NT Wonder Introduction)
NT Wonder is an extremely easy-to-use that is used to update 5091 code reader. Also, it allows you
to upload recorded test results to your PC or laptop for analysis and printing. Still, it enables you to
search DTC, read the manuals as well set up the language and style of the application.
This section illustrates how to use NT Wonder to perform its functions:
● Updating the Code Reader
● Printing
● Searching DTC
● Read the manuals
● Update tool settings
9.1 Updating the Code Reader
5091 is able to be updated to keep you stay current with the latest development of diagnosis.
To update the code reader, you need following tools:
● 5091 OBDII/EOBD Code Reader
● Update Tool NT Wonder
● PC or laptop with USB Ports and Internet explorer
● USB cable
To be able to use update tool, PC or laptop must meet the following minimum requirements:
● Operation System: Win98/NT, Win ME, Win2000, Win XP, VISTA and Windows 7/8/10.
● CPU: Intel PIII or better
● RAM: 64MB or better
● Hard Disk Space: 30MB or better
● Display: 800*600 pixel, 16 byte true color display or better
● Internet Explorer 4.0 or newer
IMPORTANT Do not disconnect the code reader from computer, or power off the computer during the
process of updating.
To update the code reader:
1. Download the update tool NT wonder and update files from our website and save the
applications and files in computer disk.
2. Unzip the update tool file. Follow instructions on computer screen to install the tool and driver.
3. Double click the desktop icon to launch the application.
4. Connect 5091 to computer with the USB cable provided.
5. Press and hold the Help key for 5s to enter the Update Mode, and the application detects
5091 automatically.
Figure 9-1 Sample Update Mode Screen
NOTE
After entering update mode successfully, there are two different ways for you to update the
device.
● Update online: With internet connection, the tool NT Wonder automatically detects the software
version of the code reader and read the latest software version from the server. If any new
diagnosis software found, it will automatically upgrade your 5091. Otherwise a prompt of new
version not detected displays.
● Update offline：Update files will be automatically stored in your computer hard drive with every
successful online update. When picking Update offline, the update tool NT Wonder will detect
these local files automatically and display them in a list. Ticking o ne of them will lead to an
update process, which eliminates the need to download any file.
6. Click <Update online> or <Update offline> t o start updating according to the software version
conditions.
Figure 9-2 Sample Update Process Screen
7. A Update Finished Message displays when the update is completed.
Figure 9-3 Sample Update Done Screen
9.2 Printing
The Print Data function is used to print test results through computer. It is not available to perform this
function when the device is in Update Mode.
To print test results:
1. Download and launch NT Wonder as instructed on page 44 of 9.1 Updating the Code Reader
.
2. Activate the application by clicking the Print Button from the menu.
