Speaker
setup
Configuration
(Select
according to
connected
speaker and
power
amplifier)
2X (configuration when seven channels are
connected)
First step: select the audio channel mode
L/R: select this option if your power
amplifier is compatible with Dolby Pro
Logic;
Stereo: select this option if the player is
connected to stereo power amplifier.
Second step: set the selected speaker as
follows: Size: set according to speaker size,
select large if the cross section area is
larger than or equals to
16cm , or else
select small;
Tuning: adjust the audio output strength of
the speaker in the range -10~10dB.
Delay: set the distance between the
speaker and the listener by 5cm in the
range 0~1000cm.
