Latronics PVE1200 - Special Features

12
SPECIAL FEATURES
DigitalEnergyDisplay
NightTimeDisconnect
ParallelOperation
Note:
MaximumPowerPointTracking
Protection
MaintenanceCycle
Thebacklitenergydisplayshowsinstantaneouspower,accumulativepower,
ACvoltage, ACcurrent, ACpowerfactorand ACfrequency.Seepage14for
moredetails.
AfterdarkwhenthesolarinputisnolongeravailabletheInverterwill
automaticallydisconnectfromthe ACgrid. Thisfeatureensuresthatduring
thenight,theInvertercannotconsumeanypowerwhatsoeverwhile
remainingidle.Uponsunrisethenextmorningwhensolarinputbecomes
availableagain,thePVedgewillautomaticallyreconnecttothe ACgridand
begingeneratingpower.
ThePVedgeautomaticallysynchronizestothe ACgrid,thereforetheoutput
ofmultipleunitscanallbeconnectedtogether,andtheywillallbe
synchronizedbythe ACgrid.
Theoptimumpowerlevelfromthesolarinputdependsontheavailablesolar
modules.Evenincloudyweatherwithfluctuationsinthesolarradiation
level,thePVEdgeconstantlymonitorsandtrackstheoptimumoperating
pointtoensuremaximumpowerfromthesolarmodulesisachieved.
The ACgridvoltageandfrequencyiscloselymonitoredbythePVEdge
alongwithantiislandingchecksviaactivephaseshifts.Isolationbetween
theDCinputand ACoutputisachievedviathe Toroidal Transformer. The
Inverterisfittedwithacoolingfan,whichistemperaturecontrolledandonly
operateswhenrequired.
WheninBatterymode(MPPT disabled)amaintenancecycleisperformed
every30days. Thisisashortboostcycleforsealedbatteriesoranequalize
chargeforfloodedcells.InthismodethebottomLEDwillflashslowlyuntil
thecycleiscompleted.
TheSolarinputsofmultipleunitInvertersarenottobeparallelled
unlessusedwithabattery.PleasecontactLatronicsformoredetails.
9
TheLatronics TurbineControllerutilizesthelatestinmicro-controllerdesigntodelivera
stableandsafesupplyofpowertothegridconnectinverter.Designedspecificallyto
integratewiththePVEdgelineofLatronicsinverters,itallowsbattery-lessgrid
connectionofwindandwaterturbines.
NOTE:
PVEdgemustbeinBatteryMode.
Turbinecontrollermayrequireadumpload.
(Seepg13)
(see TurbineControllermanual)
Turbine
Controller
GridMains
Turbine
3PhaseorDCVoltage
PVEdge
