6. Connectthe Active,NeutralandEarthcablesasperdiagrambelow.
7.PushthesocketbackintotheMainBodyuntilitclipsin.
8.ScrewthePressureRingbackintoformatightseal.
9.PlugintoPVEdge.
Todisconnecttheplug,simplypushthereleaseclipinandunplug.
Note: Thereleaseclipsectioncanbecompletelytakenoutifalockable
connectorisnotdesired.
N
L
E
Neutral
Active
Earth
Socket
15
FAULTFINDING
HELPFUL HINTS
ShouldtheInverterappeartobemalfunctioningwesuggestthefollowingto
eliminateanyexternalproblems.
TurntheInverterOFFbyswitchingtheExternalDCand ACisolators
OFF.LeaveOFFfor60seconds.
ReconnecttheDCSolarInputbyswitchingexternalDCIsolatorON. All
lightsontheInvertershouldcomeONfor1secondatpowerupand
thengoOFF. The75%lightshouldremainONtoindicatetheSolar
Inputisavailable.SolarInputvoltageneedstobeabovetheautomatic
turnONvoltage,forthelighttoturnON .Ifthelightdoesnot
illuminatecheckSolarInputforcorrectoperation.
Nextreconnectthe ACgridbyswitchingtheexternal ACbreakerON.
After20secondsthe75%lightshouldbeginflashingtoindicateInverter
reconnectingtothe ACgrid. Thelightwillflashfor60secondswhilethe
PVEdgechecksthatthemainsvoltageandfrequencyarestable.
Shouldthelightnotbeginflashingcheckifthe ACgridispresent.
Afterthe75%lightstopsflashingtheInverterwillbeginfeedingpower
intothe ACGrid.
!
!
!
!
,seepg18
MakecertainthatyouunderstandtheoperationoftheInverter.
Rememberthatithasautomaticreconnectiontothe ACgrid.
Makesureleadsandterminalsarenotcorroded,looseorfaultyinany
way.
MakesureallexternalDCand ACisolatorsareresetproperly.Ifunsure
switchOFFandONagain.
!
!
!
!
6
Pushtorelease
