Bath/Circulation thermostats
E 103 E 111 E 119 E 125
Operating temperature range ➀ 0 23 to 120
“with water cooling °C 20 to 120
Operating temperature range ➁ °C -20 to 120
Heater
power
230 V; 50/60 Hz
115 V; 60 Hz
100 V; 50/60 Hz
kW 1.5
1,3
1,0
Pump type pressure pump with choice of 5 output steps
Max. discharge pressure ➂ bar 0.4
Max. flow rate ➂ l/min 17
Pump connections mm nipples 13 mm dia.
Max. bath volume l 2,5 to 3.5 9 to 12 12 to 18 19 to 25
Bath deep-drawn inner vessel, steel casing painted
Bath opening (WxD) mm 135x105 300x190 300x365 300x365
Bath depth ➃ mm 150 150 150 200
Usable depth ➃ mm 130 130 130 180
Height top edge of bath mm 178 178 178 228
Overall size (WxD) mm 168x271 331x360 331x536 331x536
Height mm 349 349 349 399
Weight kg 6 9 10 12
Ref. No. 230 V; 50/60 Hz
115 V; 60 Hz
100 V; 50/ 60Hz
LCB 0691
LCB 4691
LCB 6691
LCB 0693
LCB 4693
LCB 6693
LCB 0695
LCB 4695
LCB 6695
LCB 0697
LCB 4697
LCB 6697
E 106 T E 112 T E 115 T E 120 T
Operating temperature range ➀ °C 23 to 100
“ with water cooling °C 20 to 100
Operating temperature range ➁ °C -20 to 100
Heater power 230 V; 50/60 Hz
115 V; 60 Hz
100 V; 50/60 Hz
kW 1.5
1.3
1.0
Pump type pressure pump with choice of 5 output steps
Max. discharge pressure ➂ bar 0.4
Max. flow rate ➂ l/min 17
Pump connections mm nipples 13 mm dia.
Max. bath volume l 5 to 7 9 to 13 10 to 15 14 to 20
Baths polycarbonate
Bath opening (WxD) mm 130x285 300x175 275x130 300x350
Bath depth ➃ mm 160 160 310 160
Usable depth ➃ mm 140 140 290 140
Height top edge of bath mm 170 208 356 208
Overall size (WxD) mm 145x435 316x330 428x142 316x506
Height mm 330 369 517 369
Weight kg 4 7 6 8
Ref. No. 230 V; 50/60 Hz
115 V; 60 Hz
100 V; 50/ 60Hz
LCM 0091
LCM 4091
LCM 6091
LCD 0261
LCD 4261
LCD 6261
LCD 0263
LCD 4263
LCD 6263
LCD 0265
LCD 4265
LCD 6265
➀
at pump output step 1
➁
with additional cooling
➂
at pump output step 5
➃
baths
➾
section 10. Accessories
Units to EU-Directive 89/ 336/ EWG (EMC) and 73/ 23/ EWG (low-voltage) with CE-mark.
We reserve the right to make technical alterations!
