Technical data
26
9 Technical data (to DIN 58966)
Common technical data
E 100
Ambient temperature range °C 5 to 40
Setting resolution °C 0.1
Indication resolution °C 0.1
Indication accuracy °C ±0.4°C ± 0.5 % additive re-calibration from indicated value ➂
Temperature control ± °C 0,05
Safety features ➀ FL
Additional functions
Power
consumption
230 V;50/60 Hz
115 V; 60 Hz
100 V:50/60 Hz
kW 1,6
1,4
1,1
➀
FL: suitable for flammable and non-flammable liquids; NFL: only suitable for non-flammable liquids
➁
➾
Section 7.2. last item
Immersion thermostats
E 100
O
eratin
tem
erature ran
e ➀ °C 25 to 120
" with water cooling °C 20 to 120
Operating temperature range ➁ °C -20 to 120
Heater
power
230 V; 50/60 Hz
115 V; 60 Hz
100 V; 50/60 Hz
1.5
1,3
1,0
Pump type pressure pump with choice of 5 output steps
Max. discharge pressure
➂ bar 0.4
Max. flow rate➂ l/min 20
Pump connections mm nipples 13 mm dia.
Bath depth ➃ mm min 150
Usable depth ➃ mm min 100
Overall size (WxD) mm 125x133
Height (H) mm 315
Weight kg 3
Ref. No. 230 V; 50/60 Hz
115 V; 60 Hz
100 V; 50/ 60Hz
LCE 0221
LCE 4221
LCE 6221
➀
at pump output step 1
➁
with additional cooling
➂
at pump output step 5
➃
baths
➾
section 10. Accessories
Units to EU-Directive 89/ 336/ EWG (EMC) and 73/ 23/ EWG (low-voltage) with CE-mark.
We reserve the right to make technical alterations!
