Lauda Ecoline Series User Manual

Circuit dia
g
ram
32
230V; 50Hz
◆
230V; 50/60Hz
◆
[230V; 60Hz] at serial no: X01
E 1xx E 2xx E 3xx
A 1 Printed circuit board „Mains“ UL 487-1 UL 487-1 UL 487-1
A 2 Printed circuit board „Display“ UL 488-1A UL 488-1B UL 488-1C
A 3 Printed circuit board serial interface RS 232/RS 485 ---------- UL 490 UL 490
A 4 Printed circuit board Mains LED-Backlight --------- --------- UL 492
A 5 Printed circuit board Display LED-Backlight --------- --------- EAO 015
B 1 Pt100 probe safety circuit ETP 057 ETP 057 ETP 057
B 2 Pt100 probe actual value
E 1 Heater 1,5 kW EH 168 --------- ----------
E 2 Heater 2,25 kW ---------- EH 169 EH 169
M 1 Pump motor EM 109 EM 109 EM 109
S 1 Mains switch EST 101 EST 101 EST 101
U 3 SSR (BRT22H) Y 1 output A1 --------- EYI 158 ---------
X 1 Mains connection EKN 001 EKN 001 EKN 001
X 2 Lock screw --------- 2x EQZ 048 2x EQZ 048
X 8 Connection socket Cooling (Stakei 2) --------- --------- EQK 004
EQZ 006
X 10 Connection socket Cooling unit (Stakei 200) --------- --------- EQD 037
EQZ 006
X 13 Housing 2pol. --------- --------- EQF 067
X 21 Plug strip terminal 12pol. EQF 079 EQF 079 EQF 079
X 23 Line up terminal 2pol. --------- --------- EZK 063
115V; 60Hz
◆
[100V; 50/60Hz] at serial no: X01
E 1xx E 2xx E 3xx
A 1 Printed circuit board „Mains“ UL 499 UL 499 UL 499
A 2 Printed circuit board „Display“ UL 488-1A UL 488-1B UL 488-1C
A 3 Printed circuit board serial interface RS 232/RS 485 ---------- UL 490 UL 490
A 4 Printed circuit board Mains LED-Backlight --------- --------- UL 492
A 5 Printed circuit board Display LED-Backlight --------- --------- EAO 015
B 1 Pt100 probe safety circuit ETP 057 ETP 057 ETP 057
B 2 Pt100 probe actual value
E 1 Heater 1,3 kW at 115V
1,0 kW at 100V
EH 171 EH 171 EH 171
M 1 Pump motor EM 109 EM 109 EM 109
S 1 Mains switch EST 101 EST 101 EST 101
U 3 SSR (BRT22H) Y 1 output A1 --------- EYI 158 ---------
X 1 Mains connection EKN 003 EKN 003 EKN 003
X 2 Lock screw --------- 2x EQZ 048 2x EQZ 048
X 8 Connection socket Cooling (Stakei 2) --------- --------- EQK 004
EQZ 006
X 10 Connection socket Cooling unit (Stakei 200) --------- --------- EQD 037
EQZ 006
X 13 Housing 2pol. --------- --------- EQF 067
X 21 Plug strip terminal 12pol. EQF 079 EQF 079 EQF 079
X 23 Line up terminal 2pol. --------- --------- EZK 063
