14 Examples for connection to the mains supply
The standard versions of Water Baths models H 4 to H 16 A are supplied with a pre-assembled, cast-on shock-proof
plug. Make sure to connect to a protective conductor terminal.
Colour
coding of mains cable
Mains supply
ge/gr
–
yellow
/g
reen
PE
(Protective
earth
)
bl
–
blue
N
sw
–
black
L1
All Water Baths supplied for 230 V (see information on the nameplate) can be connected to all power supplies of 220 V
or 230 V. Maximum grid impedance Z
max
= 0,135 W. If necessary, this value should be requested from the responsible
energy supply company.
Electrical fuses 14.1
Model
Power
Power consumption at mains voltage *
Mains fuse
(F4, F5)
H 4 0,5 kW 2,2 Amp at 230 V 10 A / Amp
(max. 16 A / Amp.)
H 8,
H 8 A
1,0 kW 4,4 Amp at 230 V 10 A / Amp
(max. 16 A / Amp.)
H 16,
H 22,
H 24,
H 41,
H 16 A
1,5 kW 6,5 Amp at 230 V 10 A / Amp
(max. 16 A / Amp.)
* see nameplate
