Page #177 background image
Table 2 Unit IN 4 XTW IN 8 XTW Pump level
200 °C with thermal oil kW 17 17 8
150 °C with thermal oil kW 17 17 8
100 °C with thermal oil kW 10 10 8
50 °C with thermal oil kW 2 2 8
Cooling medium --- Water Water ---
Connecting thread of cooling
water internal/external
Inches G3/4“ G3/4" ---
Cooling water temperature
minimum/maximum
°C 10/30 10/30 ---
Recommended cooling water
temperature
°C 15 15 ---
Minimum dierential pressure of
cooling water
bar 3 3 ---
Maximum cooling water pres-
sure
bar 10 10 ---
Maximum cooling water con-
sumption
l/min 11 11 ---
If the maximum current consumption is limited Ä “Limiting the current
consumption” on page 101 the heating output can be reduced.
Depending on the country-specific version, the maximum current con-
sumption may already be limited ex works.
Table 3 Unit IN 4 XTW
Heating output
230 V; 50 Hz kW 3.5
200 V; 50/60 Hz kW 2.9
208-220 V; 60 Hz kW 3.1 – 3.3
Current consumption A 16
The mains plug for the United Kingdom (Great Britain) reduces the per-
formance data.
230 V; 50 Hz kW 2.8
Current consumption A 13
Heating output and power supply
V6 Integral Process Thermostats and High-Temperature Thermostats 177 / 198
