15.5 Technical data of the high-temperature thermostats
Table 1 Unit IN 4 XTW IN 8 XTW
Working temperature range °C 25 – 320 25 – 320
Temperature stability Á
K
±0.1 ±0.1
Device dimensions width x depth x height mm 430 x 550 x 760 430 x 550 x 760
Filling volume
‑ minimum L 3.3 3.6
‑ Maximum L 9.5 9.8
Pump data 50/60 Hz
‑ maximum discharge pressure bar 3.1 3.1
‑ Maximum flow rate l/min 60 60
Connecting thread (external) pump connector
inlet/outlet
mm M30 x 1.5 M30 x 1.5
Noise level 50 Hz Â
dB(A) 52 52
Noise level 60 Hz Â
dB(A) 52 52
Weight kg 78 85
Distance of device from other objects
‑ Front mm 200 200
‑ Back mm 200 200
‑ Right mm 200 200
‑ Left mm 200 200
Á - Temperature stability determined according to standard DIN 12876-2
 - Noise level determined according to standard EN 11201 for operating
position in front of the device at 1 meter distance
The noise level of the various devices was measured according to the
guidelines included in DIN EN ISO 11200 and the basic standards
cited therein. The measured values correspond to the operating
conditions that occur during typical device operation.
Table 2 Unit IN 4 XTW IN 8 XTW Pump level
Cooling output at (ambient
temperature 20 °C)
300 °C with thermal oil kW 17 17 8
Cooling output
V6Integral Process Thermostats and High-Temperature Thermostats176 / 198
