The figure shows an example of a rating label for a device with NRTL
certification.
Specification Description
SCCR: Indicates the short-circuit current according to NEC 110-10
or UL508A which the components and assemblies used in the
machine can withstand
Compressor FLA I: Current consumption of Compressor I under full load
Compressor HP I: Power of Compressor I in horse power
Compressor FLA II: Current consumption of Compressor II under full load
Compressor HP II: Power of Compressor II in horse power
Pump FLA I: Current consumption of Pump I under full load
Pump HP I: Power of Pump I in horse power
Pump FLA II: Current consumption of Pump II under full load
Fig. 15: Rating label (example)
V6 Integral Process Thermostats and High-Temperature Thermostats 31 / 198
