Hoses, insulated at the factory
Type
Pump connec-
tions
Application area
Internal Ø
in mm
External diam-
eter in mm
Tem-
perature
range in
°C
Catalogue
number
EPDM
hose, insu-
lated
Olive 13 mm,
M16 x 1
Devices with
maximum pump
pressure of
< 1 bar
12 23 -35 ... 90 LZS 021
Insulated hoses for subsequent insulation, length 1 m
Insulation
catalogue
number
Max. temperature in
°C
Internal Ø in mm
External diameter in
mm
Suitable for hose
RKJ 058 105 19 54 RKJ 112
RKJ 024 125 16 36 RKJ 112
RKJ 009 105 23 43 RKJ 031
RKJ 013 125 29 50 RKJ 032
Adapters, suitable for MC 600 and MC 1200 (W)
Designation Description Catalogue number
Olive ¾" union nut, ½ " olive LWZ 016
Olive ¾" union nut, 10 mm olive LWZ 040
Hose clamps
Material Ø from ... to in mm Catalogue number
Stainless steel 10 ... 16 EZS 012
Stainless steel 12 ... 22 EZS 013
Stainless steel 20 ... 32 EZS 015
Before commissioning
Microcool 26
