LAUNCH
X-PROG
3
EN
No. Part Name Description
1
DB26 diagnostic connector
To connect with all anti-theft
cables.
2
Benz key slot To place Benz car key.
3
Key slot
To place car key for RF
defection.
4
Key chip slot To place key chip.
5
Power indicator
• Red light indicates faults.
• Orange light indicates
functions normally.
6
Valve
To tighten loose EEPROM
board.
7
EEPROM slot To insert EEPROM board
8
Power port For power charging
9
DB15 diagnostic connector
To connect with main diagnostic
cable.
10
DIY slot To insert vehicle DIY board.
2.2 Power Source
The product does not have an independent power supply, you can powered it
up by the followings ways:
• Use the power adapter supplied by Launch
• Connect the device through the vehicle’s DLC
