Launch TLT235、TLT240 Economical Two-post User’s Manual
37
526
201011172
Long rod axle
527 201011257
BushingⅡ
528 103203017 Pulley
529
103050035
Returning ring 25
103200967 Symmetric axle
530
103200966 Asymmetric axle
531 201011258
BushingⅠ
532 103260338 Steel cable
534 103020190 ScrewM6×10
103202810 TLT235SC Bracket for power unit
535 103202906 TLT240SC Bracket for power unit
536
103200699 Bushing2520
601
102100074
Button，NB2-BE101，green
602
102110059
Contactor(shilin）,S-P11,AC24V
603
102130043
Transformer，JBK-25,220V,380V/24V
604
102990109
Power switch LW39B-16RE04/-2-GR（small）
605
104090089
Water-proof case，240*160*90，（black）
606
102160391 cable joint PG13.5
607
102160388 cable joint PG9
608
103040109
Flat washer C class，GB/T95-1985,φ4(white zinc-plated）
609
103030009
Hex nut ，GB/T6170-2000，M4(white zinc-plated）
610
103240319 ground copper bars
611
103030009
Screw，M4*18
612
102100090 Emergency stop button LA39-11Z/r
