13 Packing
Appendix：Transportation Guide
z The packing of each model would include: 1# Angle iron bracket packing and 2# cardboard box packing. 3# top beam
packing, 4# extension column packing, Transportation guide was printed on packing.
z
While using forklift to lift the 1# packing, the distance between two forks should be at least 700mm and to the center of
the packing. The forks should cross under the load as deeply as possible and the sharp end of fork should be paid
attention not to touch goods. The forks are not allowed to pick up goods at a high speed in order to avoid packing and
goods damage cause by collision. The loads should not be stacked too high in order to avoid any collision and
products losses during transportation.
1# Angle iron
bracket packing
2# cardboard box
packing
3# top beam
packing
4# extension
column packing
Model Name
Size
Length ×Width
×Height
Size
Length ×Width
×Height
Size
Length ×Width
×Height
Size
Length ×Width
×Height
1 TLT235SB
3.5t
economical
floor-plate
two post lift
2900×540×660 850×230×300
2 TLT240SB
4.0t
economical
floor-plate
two post lift
2900×540×660 850×230×300
3 TLT235SC
3.5t
economical
clear-floor
two post lift
2900×600×650 850×230×300 2900×180×150 1180×230×390
TLT240SC
4.0t
economical
clear-floor
two post lift
2900×600×650 850×230×300 2900×180×150 1180×230×390
4
TLT240SC
(for
domestic)
4.0t
economical
clear-floor
two post lift
3920×600×650 850×230×300
5
TLT235SC
(U)
3.5t
economical
clear-floor
two post lift
3920×600×650 860×520×390 2900×180×150
