22 American Dryer Corp. 112146-61
Program Location 03 (PL03)
HI Temp
Location to be viewed/changed.
Press “Perm Press” key.
Display will read “HI°F,” “HI Temp”
key status for 3-seconds and then
the actual temperature programmed.
If no changes, press “Perm Press”
key otherwise press “HI” or “LO”
key and then “Perm Press” key.
Temperature Increase
Temperature Decrease
Summary: HI Temp is programmable from a minimum of 100 ° F to a maximum of 190 ° F in ten-degree increment s or from a
minimum of 38° C to a maximum of 88° C in five-degree increments.
PL03
HI°F
Automatically goes
into PL04 Program without
PL04 Display Mode
Perm Press
150F HI Temp
Perm Press
LO Temp
Refer to Programming
Instructions for instructions on
entering program locations.
(Wait 3-Seconds)
Continued on next page
To Next Page
