PARTS AND FEATURES

25CC 2-CYCLE ENGINE PART LIST

Key

Number

Application Description Quantity

1 321007120 Rear Engine Cover 1

2 321007121 Crankcase Cover 1

3 321007122 Washer 1

4 321007123 Gasket 1

5 321007124 Cylinder 1

6 321001139 Spark Plug 1

7 321007125 Ignition Coil Assembly 1

8 321007126 Conductor Plate 1

9 321007127 Insulation Sheet 1

10 321007128 Mufer 1

11 321007129 Mufer Cover 1

12 321007130 Gasket 1

13 321007131 Cables 2

14 321007132 Clutch 1

15 321007133 Clutch Cover Assembly 1

16 321007134 Connection Cover 1

17 321007135 Electric Start Motor 1

18 321007136 Front Engine Cover 1

19 321007137 Gear 1

20 321007138 Volute Spring 1

21 321007139 Ratchet Wheel 1

22 321007140 Dust Filter 1

23 321007141 Upper Engine Cover 1

24 321007142 Dual Gear Shaft 1

25 321007143 Dual Gear 1

26 321007144 Corrugated Pipe 1

27 321007145 Cables 1

28 321007146 Cables 1

29 321007147 Flywheel Cover Assembly 1

30 321007148 Flywheel 1

31 321007149 Crankcase Assembly 1

32 321007150 Connection Shaft 1

33 321007151 Retainer Ring 2

34 321007152 Piston Pin 1
