PARTS AND FEATURES
35 321007153 Piston 1
36 321007154 Piston Ring 1
37 321007155 Gasket 1
38 321007156 Carburetor Mount Assembly 1
39 321007157 Carburetor Washer 1
40 321007158 Carburetor (with one sheet) 1
41 321007159 Air Filter Base 1
42 321007160 Choke Lever 1
43 321007161 Air Filter 1
44 321007162 Air Filter Cover 1
45 321007163 Rubber Pad 4
46 321007164 Fuel Tank Assembly 1
46.1 321007165 Protective Film 1
47 321007166 Fuel Tube 1
48 321007167 Fuel Cap 1
49 321007168 Clutch Washer 1
50 321007169 Gasket 1
51 321007170 Washer 1
52 321007171 Gasket 2
53 321007172 Washer 1
54 321007173 Tower Spring 1
55 321007197 Screw 2
56 321007183 Screw 1
57 321007176 Washer 1
58 301002177 Self-Tapping Screw 9
59 321007177 Screw Assembly 5
60 321007178 Screw Assembly 3
61 321007179 Screw Assembly 6
62 321007180 Screw Assembly 2
63 131017110 Self-Tapping Screw 4
64 321007181 Screw 2
65 321001131 Nut 1
66 321007182 Bolt 2
