GENERAL TROUBLESHOOTING

■ The ywheel can be removed by a puller with hooks (Fig. 22). Choose an appropriate puller to

remove the ywheel. Before using the puller, rotate the screw rod

counter-clockwise until it is 1/4

to 1/2 its original length. Ensure hooks

and

are longer than screw rod

. Insert hooks

and

onto both sides of ywheel as shown in Fig. 22. Make sure the hooks are level and with the same

length. Then use a spanner to rotate screw rod

clockwise until the ywheel is removed. Rotate

the screw rod counter-clockwise to remove the puller from the ywheel.

Fig. 21

Fig. 22

Flywheel (Rotor) Replacement

(See Figs. 21-25)

■ Remove the rear engine cover, connection cover and front engine cover referring to steps 5 – 9 in

Ignition System section.

■ Remove the ywheel cover assembly and washer (Fig. 21).

Flywheel Cover

Assembly

Washer

LawnMaster NPTGSP2517A Service Manual
