LawnMaster NPTGSP2517A Service Manual

34
AIR & FUEL SYSTEM
■ Turn the Phillips screwdriver counter-clockwise to remove the 2 screws on the electric start motor
(Fig. 58).
Fig. 58
■ Remove the electric start motor. Open the corrugated pipe and separate the stop switch cables and
motor drive lines, then remove and replace the electric start motor if needed (Fig. 59).
Fig. 59
1
2
Stop Switch
Cables
Electric Start Motor
Motor Drive Lines
Corrugated Pipe
