LawnMaster NPTGSP2517A Service Manual

39
THROTTLE AND STARTER SYSTEM
■ Wrap the wiring harness of the engine with the opened corrugated pipe. One end of the wiring
harness is exposed and another end of the power lines should be straightened out and thrust into
the engine cover.
■ Wrap the connected terminals of the wiring harness with the corrugated pipe and tighten with the tie
(Fig. 78 & 79).
■ Recheck to ensure that all the insulation covering outside the wiring harness should wrap the
terminals completely and all the metal terminals are not exposed. The upper and lower covers of
the corrugated pipe buckle must be connected tightly, without any warp or twist.
Fig. 79Fig. 78
