Layher ZIFA User Manual

26
12. PARTS LIST
Tower model
Article No. 1406200 1406210 1406213 1406214 1406215 1406216
Guardrail 1.80 m 1205.180 0 2 4 9 8 13
Diagonal brace 2.50 m 1208.180 0 0 1 2 4 4
Diagonal brace 1.95 m 1208.195 0 0 0 1 0 1
Basic tube 1.80 m 1211.180 0 0 1 1 1 1
End toe board 0.75 m 1238.075 0 0 2 2 2 2
Toe board 1.8 m, with claw 1239.180 0 0 2 2 2 2
Deck 1.8 m 1241.180 1 0 1 0 1 0
Access deck 1.8 m 1242.180 0 1 1 2 2 3
Spring clip 1250.000 0 4 8 12 12 16
Ladder frame 75/4 – 1.00 m 1297.004 0 2 0 2 0 2
Ladder frame 75/8 – 2.00 m 1297.008 0 0 2 2 4 4
Uni assembly hook 1300.001 0 0 1 1 1 1
Zifa 75 basic tower 1300.006 1 1 1 1 1 1
Castor 400 – 4 kN 1308.150 4 4 4 4 4 4
Mobile beam 1.80 m with
ledger
1323.180 0 0 2 2 2 2
Ballast 1249.000 For the number of ballasting weights see the ballasting table, page 8
Tower model
Article No. 620 621 622 623 624 625
Guardrail 1.80 m 1205.180 0 2 4 4 4 8
Diagonal brace 2.50 m 1208.180 0 0 0 0 2 3
Diagonal brace 1.95 m 1208.195 0 0 0 0 0 0
Horizontal diagonal brace 1.95 m 1209.180 0 0 0 0 0 1
Basic tube 1.80 m 1211.180 0 0 0 0 0 1
End toe board 0.75 m 1238.075 0 0 2 2 2 2
Toe board 1.8 m, with claw 1239.180 0 0 2 2 2 2
Deck 1.8 m 1241.180 1 0 0 0 0 0
Access deck 1.8 m 1242.180 0 1 1 1 1 2
Spring clip 1250.000 0 4 4 8 12 16
Ladder frame 75/4 – 1.00 m 1297.004 0 2 0 0 0 0
Ladder frame 75/8 – 2.00 m 1297.008 0 0 0 0 0 0
Zifa 75 basic tower 1300.006 1 1 2 2 3 4
Castor 400 – 4 kN 1308.150 4 4 4 4 4 4
Mobile beam 1.80 m without ledger 1214.180 0 0 0 2 2 2
Ballast 1249.000 For the number of ballasting weights see the ballasting table, page 9
Tower models
1406200 – 1406216
Zifa P2
Tower models
620 – 625
Zifa – minimum requirements according to DIN EN 1004
