PAGE 6
RT-100 Connections
The RT-100 has three connectors:
•
ANT SO-239: Output to the antenna. Connect the antenna to this SO-239.
•
GND (wingnut): Connect to antenna system ground.
•
Radio SO-239: Connect to the feedline which comes from the optional RC-100 or bias tee.
