Tel: (86)755-26434369 9 Website: www.leadshine.com
Prepare Power Supply
Regulated or Unregulated Power Supply
Both regulated and unregulated power supplies can be used to supply the driver.
However, unregulated power supplies are preferred due to their ability to withstand
current surge. If regulated power supplies (such as most switching supplies.) are
indeed used, it is important to have large current output rating to avoid problems
like current clamp, for example using 4A supply for 3A motor-driver operation. On
the other hand, if unregulated supply is used, one may use a power supply of lower
current rating than that of motor (typically 50%～70% of motor current). The reason
is that the driver draws current from the power supply capacitor of the unregulated
supply only during the ON duration of the PWM cycle, but not during the OFF
duration. Therefore, the average current withdrawn from power supply is
considerably less than motor current. For example, two 3A motors can be well
supplied by one power supply of 4A rating.
Selecting Supply Voltage
The DCS810S can actually operate within +18V to +80VDC, including power input
fluctuation and back EMF voltage generated by motor coils during motor shaft
deceleration. The rated voltage of the motor is an important parameter when
selecting supply voltage. Generally speaking, do not use a power supply voltage
more than 5 volts of the rated voltage of the motor. Higher voltage may cause bigger
motor vibration at lower speed, and it may also cause over-voltage protection or
even driver damage.
Prepare Controller
Prepare a controller with pulse and direction signals. However, the DCS810S has a
built-in motion controller for self-test and Servo Tuning. The built-in motion
controller can generate control signal with trapezoidal velocity profile.
D
D
C
C
S
S
8
8
1
1
0
0
S
S
D
D
i
i
g
g
i
i
t
t
a
a
l
l
D
D
C
C
S
S
e
e
r
r
v
v
o
o
D
D
r
r
i
i
v
v
e
e
r
r
M
M
a
a
n
n
u
u
a
a
l
l
R
R
e
e
v
v
1
1
.
.
0
0
Tel: (86)755-26434369 10 Website: www.leadshine.com
System Connections and Noise Prevention
After finishing the above steps, you can connect your servo system. Before you start,
make sure that the power is off. Connect your system according to connection
diagrams before, and pay attention to the following tips when wiring.
Wire Gauge
The smaller wire diameter (lower gauge), the higher impedance. Higher impedance
wire will broadcast more noise than lower impedance wire. Therefore, when
selecting the wire gauge, it is preferable to select lower gauge (i.e. larger diameter)
wire. This recommendation becomes more critical as the cable length increases. Use
the following table to select the appropriate wire size to use in your application.
Current (A) Minimum wire size (AWG)
10 #20
15 #18
20 #16
Cable Routing
All content sensitive signal wires should be routed as far away from motor power
wires and driver power wires as possible. Motor power and driver power wires are
major sources of noise and can easily corrupt a nearby signal. This issue becomes
increasingly important with longer motor power and driver power wires lengths.
Twisted Wires
Twisted wires effectively increasing noise immunity. The successive twists eliminate
noise transients along the length of the cable. Both signal cables and power cables
should be of the twisted and shielded type. Differential signal wires should be
twisted as a pair. The combination of twisted pair wires and a differential signal
significantly adds to noise immunity. Power wires should be twisted as a group
To Next Page
