Introduction to Integrated Servo Motor
Leadshine’s iSV-B23xxx integrated servo motor is a NEMA 23 brushless motor integrated with a 1,000-line (4,000
PPR) encoder and a servo drive. At very compact size and with all components integrated, the iSV-B23xxx can save
mounting space, eliminate encoder connection & motor wiring time, reduce interference, and cut/reduce cable and
labor costs.
Applications
Leadshine’s iSV-B23xxx can be used in various applications such as laser cutters, laser markers, high precision X-Y
tables, labeling machines, CNC router, etc. Its unique features make the iSV-B23xxx an ideal choice for applications
that require both low-speed smoothness and small mounting space.
Drive Motor
BLDC Motor
Encoder
Amplifier
Comparator
Comp
Command Position
Measured Position
Integrated Servo Motor
