10
NOTICE
The top battery module must be
secured to the wall.
1.2N.m
3
Tighten the four screws
on both sides
4
Secure the PCU
to the battery
Secure the battery modules in the
midddle to the wall.(Optional)
Install the remaining battery modules and power
control unit from bottom to top. After installing a
module, secure the left and right mounting holes,
and then install secure the battery to the wall.
