Installing Battery
3.3
NOTICE
• The following describes how to install the battery expansion modules for a 20kWh model.
• The installation of battery for 5kWh, 10KWh and 15kWh models is the same. One battery
expansion module is installed for a 5kWh model, two battery expansion modules are
installed for a 10kWh model, three battery expansion modules are installed for a 15kWh
model.
1.2N.m
Tighten the four screws on both sides
Secure the first battery module to the
wall.
You can adjust the two connecting pieces
vertically to align with the screw holes.
5N.m
NOTICE
You need to secure the left and right screws
on both sides first.
1
2
Align the first battery module with the
support on the base support
