Leapton EHA05-5 - Connecting the Communication Cable

WWW.leaptonpv.com
13
Connecting the Communication Cable
4.3
3
4
1
2
1
4
3
2
1
2
3
4
3
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
CAN_GND2
Addr_IN
CANH2
CAN3H
CAN3L
CANL2
/
/
1
2
3
4
5
6
7
8
CAN_GND2
Addr_OUT
CANH2
CANL2
/
/
/
/
CAN
PIN LINK
Description
BMS communication for battery
system parallel connection
Connects to the invert BMS
communication port to communication
with the invert
BMS communication for battery
system parallel connection
/
/
