MyWay+ User Manual p.50
18.0 Technical Information
Size 1 Frame Size 2 Frame Size 3 Frame
Age (approx.) 1-5 4-11 9-16
User Shoulder Height (to oor) (mm) 590 – 870 870-1190 1070 – 1490
User Saddle Height (inside leg) (mm) 240 – 410 400-610 550 - 810
Max. User Weight (kg) 25 50 80
Frame Weight (kg)
14 (S1 frame and
upper support unit do
not separate)
7.5 11
Upper Support Unit Weight (kg) 10 11
Frame Width (mm) 570 670 720
Frame Length (mm) 840 930 1180
Harness Size Age (Approx) Waist at Navel Level (cm) Max. User Weight (kg) Colour
1 1-4 46-56 50kg Purple
2 2-6 50-60 50kg Green
3 5-9 55-65 50kg Blue
4 8-12 60-70 80kg Red
5 12-15 70-80 80kg Orange
6 16-18 80-90 80kg Grey
Warning – The maximum user weight for this product is determined by the
combination of frame and harness sizes selected- the maximum user weight is
the lower of these limits. For example, if a Size 3 frame and a Size 3 harness are
selected, the maximum user weight is 50kg, as determined by the harness limit.
