MyWay+ User Manual p.9
9.0 Main Frame Set-Up/Features
9.1 Frame | Unfolding the Frame
• Lift the frame out of the box and set it on a at,
stable surface, keeping it in the same position
as it was packaged within the box i.e. as per
image below.
• Stand at the base of the frame’s
‘U’ shape. Pull both triggers.
• Walk the frame’s front legs forward,
away from you (in direction of arrows),
engaging the front castors until the legs
are fully extended. Release both triggers.
Warning – when lifting the
frame, adhere to normal
moving and handling
procedures.
Warning – ngers should
be placed on triggers as
shown, to avoid potential
for nger nipping.
Warning – if the red rectangle is visible
on the triggers once these have been
released, the frame legs have not been
fully locked out.
Scan the QR code
with your phones
camera to view
