Press adjacent Operation buttons and use the Digital Input Front Panel
Controls (on page 27) to make specific adjustment/selection parameter
choices. For more information on getting to this point, see Navigating
Interfaces, Adjusting Parameters, and Making Selections (on page 16).
PLEASE NOTE THE FOLLOWING:
Arb Operation menu selections and parameters include
Frequency/Period, Amplitude/HLevel, Offset/LLevel,
Phase/EqPhase, and Load Wform. The parameters
forFrequency/Period, Amplitude/HLevel, Offset/LLevel, and
Phase/EqPhase are carried out the same way as done when
Creating a Sine Wave (on page 28).
Operation menus containing more parameters than the ones
showing on the first menu have a 1/X ↓ final selection. The
additional menu(s) therefore have a 2/X ↑ first selection. Press
the adjacent button to navigate additional menu(s) and
parameter(s) as desired.
Loading a Stored Waveform is done as follows:
Load Wform
Press the 1/2 ↓ button to access the additional Arb Operation
menu.
Now, press the Load Wform button.
An Arb menu showing Built-In and Stored Waveform options is
shown.
Note: There are 40+ Built-In Arbitrary Waveforms available in
the WaveStation.
