Default - The Sync signal should be connected to the
activated Sync Out connector on the Back Panel.
When the Sync Signal is disabled, the output voltage
of the [Sync] connector is set to low level.
Inverse - In this mode, the Waveform corresponding
to the Sync Signal does not inverse.
Non-Modulated Waveforms - The Sync Signal
reference is the carrier signal on non-modulated
waveforms.
AM, FM, and PM - Internal modulating waveforms
(AM, FM, and PM) the Sync signal reference is the
modulated signal
ASK and FSK - The Sync Signal Reference is the
keying Frequency.
Sweep - Once the sweep starts, the Sync Signal
becomes TTL Level High. The Sync frequency equals
the specific Sweep time.
Burst - For the Burst, when the burst starts, the Sync
Signal is Level High.
External Gated Burst - The Sync Signal follows the
External Gated Signal.
Pulse - The Sync Signal is a Pulse Signal with a fixed
positive pulse width more than 50 ns.
o ChCopy - Press this option button and an additional menu is
provided where you can port a particular channel's
configuration to another. Option buttons are labeled as
CH1->CH2 and CH2->CH1 accordingly.
Make selections as desired and press the Done (to commit)
or Cancel option button and the main Util menu is shown.
