Dual Channel Digital Receiver
Rio Rancho, NM
17
INTERRUPTED
RECORDING
FOUND
And then:
Recover?
for safe use
see manual
No
Yes
If “No” is chosen, nothing is done to the card and the
DCR822 will not use the card. If “Yes” is chosen”, a
prompt appears asking for the length of the recording
to recover, specified as a number of hours and minutes.
The default suggestion will be the approximate length of
the most recent recording. It is always safe to recover a
longer recording than was made. To specify the recov-
ery time, use the MENU/SEL button to navigate and
specify the hours and minutes fields.
Length to
recover?
hh mm
08: 10
Once set as desired, use MENU/SEL to reveal the “GO”
soft button and press the DOWN button button to begin
the recovery process. Recovery is nearly instantaneous.
When completed, the display will show:
RECOVERY
SUCCESSFUL
IR & Keys Menu
The operations below depend on the compatibility mode
selected and the transmitter used. The DCR822 has
two-way IR for use with digital products (DBu, DBSM,
etc.) and one-way IR for use with older IR-capable units
such as LT and HMa. One-way protocol can only “Send
Frequency.”
NOTE: You must position the transmitter’s IR port
directly in front of the DCR822 IR port, as closely
as possible, to guarantee a successful sync.
Send Frequency
Sends operating frequency to the transmitter, each
channel separately. Press the UP button to send the
Channel 1 frequency, and the DOWN button to send the
Channel 2 frequency. Success for digital compat modes
is indicated on the receiver as “IR Sync OK.” For digital
modes, failure will be indicated on the receiver as “IR
SYNC FAILED.” For Hybrid compat modes, success will
be indicated on the transmitter as “IR SYNC.” Failure will
be indicated on the transmitter as “CP Err” or “Block
Mismatch” depending on the transmitter model and the
source of the error.
Send All
(available only for digital compat modes)
Sends frequency, channel name/s, and Talkback state
to the transmitter. Press the UP button to send the
information from Channel 1, and the DOWN button to
send the information from Channel 2. Since two-way IR
Sync is only available for digital transmitters, “N/A” will
be next to any channels that are in a Hybrid compatibility
mode.
Get Frequency
(available only for digital compat modes)
Send or retrieve (get) frequency from the transmitter.
Choose encryption type by pressing the UP and DOWN
buttons. Select MENU/SEL to get frequency.
Get All
(available only for digital compat modes)
Retrieve (get) transmitter’s frequency, Talkback state, and
channel name. Press the UP button to get all and use for
Channel 1. Press the DOWN button to get all and use for
Channel 2. Since two-way IR Sync is only available for
digital transmitters, “N/A” will be next to any channels that
are in a Hybrid compatibility mode.
Group Sync
These functions allows you to send or get frequency
groups via IR sync to/from transmitters and receivers
capable of using Groups (DCR822, DCHR, DBSM,
DBSMD, DPR, DPR-A). Use MENU/SEL button to
navigate between the group choice and the send/get
mode. With the group letter highlighted, use the UP or
DOWN buttons to select which frequency group to send
or get. Then press the MENU/SEL button to select Send
or Get. Use the UP or DOWN buttons to toggle between
Send or Get. Then, press MENU/SEL again and “Go” will
appear in the lower right corner. Press the DOWN button
to complete the sync operation.
