29
Commissioning
4.5.6 Network Parameters
Code Possible Settings
IMPORTANT
No. Name Default Selection
p400
Network Protocol 0 Not Active
This parameter will only display
the selection for the module that is
installed.
1 Remote Keypad
2 Modbus RTU
3 CANopen
4 DeviceNet
5 Ethernet
6 Profibus
p401P499
Module Specific Parameters
Refer to the Reference Guide specific
to the module installed.
4.5.7 Diagnostic Parameters
Code
Display Range
(READ ONLY)
IMPORTANT
No. Name
p500
Fault History Displays the last 8 faults
Format: n.xxx
where: n = 1..8;
1 is the newest fault
xxx = fault message (without the
F.)
see Section 5.3
P501
Software version Format: x.yz
P502
Drive ID A flashing display indicates that the Drive ID
stored in the EPM does not match the drive
model it is plugged into.
P503
Internal Code Alternating Display: xxx-; -yy
P505
DC Bus Voltage 0 {VDC} 1500
P506
Motor Voltage 0 {VAC} 1000
P507
Load 0 {%} 255 Motor load as % of drive’s output current rating.
See section 2.2.
P508
Motor Current 0.0 {A} 1000 Actual motor current
P509
Torque 0 {%} 500 Torque as % of motor rated torque
(vector mode only)
P510
kW 0.00 {kW} 650.0
P511
kWh 0.0 {kWh} 9999999 Alternating display: xxx-; yyyy when value
exceeds 9999
P512
Heatsink Temp 0 {°C} 150 Heatsink temperature
P520
0-10 VDC Input 0.0 {VDC} 10.0 Actual value of signal at TB-5
P521
4-20 mA Input 0.0 {mA} 20.0 Actual value of signal at TB-25
P522
TB-5 Feedback P204 P205 TB-5 signal value scaled to PID feedback units
P523
TB-25 Feedback P204 P205 TB-25 signal value scaled to PID feedback units
