Technical data
2.2 Ratings
120VAC Doubler / 240VAC Models
Type Power
[Hp/kW]
Mains Output Current
Watts
Loss
Voltage
(1)
I
in
(120V) I
in
(240V) I
n
CLim
max
(2)
0.33 / 0.25
120 V Single-phase (1/N/PE)
(90 … 132 V)
OR
240 V Single-phase (2/PE)
(170 … 264 V)
6.8 3.4 1.7 200 24
0.5 / 0.37 9.2 4.6 2.4 200 32
1 / 0.75 16.6 8.3 4.2 200 52
240VAC Models
Type Power
[Hp/kW]
Mains Output Current
Watts
Loss
Voltage
(1)
I
in
1~ (2/PE) I
in
3~ (3/PE) I
n
CLim
max
(2)
0.33 / 0.25
240 V Single Phase (2/PE)
3.4 - 1.7 200 20
0.5 / 0.37
240 V Single-phase (2/PE)
OR
240 V Three-phase (3/PE)
(170 … 264 V)
5.1 2.9 2.4 200 27
1 / 0.75 8.8 5.0 4.2 200 41
1.5 / 1.1 12.0 6.9 6.0 200 64
2 / 1.5 13.3 8.1 7.0 200 75
3 / 2.2 17.1 10.8 9.6 200 103
1.5 / 1.1
240 V Three-phase (3/PE)
(170 V … 264 V)
- 6.9 6.0 200 64
2 / 1.5 - 8.1 7.0 200 75
3 / 2.2 - 10.8 9.6 200 103
5 / 4.0 - 18.6 16.5 200 154
7.5 / 5.5 - 26 23 200 225
10 / 7.5 - 33 29 200 274
(1) Frequency Range: 48 Hz … 62 Hz
(2) Current Limit (CLim) is a percentage of the output current, I
n
. CLim
max
is the maximum setting for P171.
