20.0 USER SETTING RECORD

PARAMETER MENU: USER SETTING RECORD

PARAM. PARAMETER FACTORY USER

NUMBER NAME DEFAULT SETTING

0 LINE VOLTS AUTO

1 SPEED #1 20.00 Hz

2 SPEED #2 20.00 Hz

3 SPEED #3 20.00 Hz

4 SPEED #4 20.00Hz

5 SKIP #1 .00 Hz

6 SKIP #2 .00 Hz

7 BAND WID 1.00 Hz

8 ACCEL 30.0 SEC

9 DECEL 30.0 SEC

10 MIN FRQ .50 Hz

11 MAX FRQ 60.00 Hz

12 DC BRAKE .0 VDC

13 DC TIME .0 SEC

14 DYN BRAKE OFF

16 CURRENT 180%

17 MOTOR OL 100%

18 BASE 60.00 Hz

19 FX BOOST (NOTE 1)

NOTE 1: REFER TO SECTION 18.0 - DESCRIPTION OF PARAMETERS.
