10
230 VOLT MICRO SERIES RATINGS
MODEL
INPUT OUTPUT
(200/240 Vac, 50-60 Hz) (0-200/230 Vac)
FOR MOTORS NOMINAL NOMINAL
CATALOG RATED INPUT CURRENT POWER CURRENT POWER
NUMBER HP kW PHASE (AMPS) (KVA) (AMPS) (KVA)
174914
174935* .50 0.37 3 3.1/2.7 1.1 2.5/2.2 0.88
174527**
174915
174936* 1 0.75 3 5.5/4.8 2.0 4.6/4.0 1.6
174528**
174916
174482* 1.5 1.1 3 7.1/6.2 2.6 6.0/5.2 2.1
174529**
174917
174937* 2 1.5 3 9.3/8.1 3.4 7.8/6.8 2.7
174530**
174918
174938* 3 2.2 3 13.0/11.3 4.7 11.0/9.6 3.8
174531**
174919
174730* 5 3.7 3 20.0/17.7 7.4 17.5/15.2 6.1
174732**
174545
174734* 7.5 5.5 3 30/26 10.6 25/22 8.8
174735**
174551
174737* 10 7.5 3 37/32 13.2 32/28 11.2
174738**
174557
174740* 15 11 3 55/48 19.8 48/42 16.7
174741**
174560
20 15 3 70/61 25.3 62/54 21.5
174743*
174569
25 18.5 3 89/77 32.0 78/68 27.1
174595*
174571
30 22 3 104/90 37.6 92/80 31.9
174596*
NOTE See Section 8.0 for recommended fuse type.
* = NEMA 4/12 or 12 ENCLOSURE
** = NEMA 4X ENCLOSURE
OTHERS ARE NEMA 1 ENCLOSURE
