575 VOLT MICRO SERIES RATINGS
MODEL
INPUT OUTPUT
(480/590 Vac, 50-60 Hz) (0-460/575 Vac)
FOR MOTORS NOMINAL NOMINAL
CATALOG RATED INPUT CURRENT POWER CURRENT POWER
NUMBER HP kW PHASE (AMPS) (KVA) (AMPS) (KVA)
174925
174943* 1 0.75 3 1.9 / 1.9 1.9 1.6 / 1.6 1.6
174536**
174926
174944* 2 1.5 3 3.3 / 3.3 3.4 2.7 / 2.7 2.7
174537**
174927
174945* 3 2.2 3 4.6 / 4.6 4.7 3.9 / 3.9 3.9
174538**
174928
174946* 5 3.7 3 7.1 / 7.1 7.3 6.1 / 6.1 6.1
174539**
174929
174549* 7.5 5.5 3 10.5 / 10.5 10.7 9.0 / 9.0 8.8
174759**
174553
174556* 10 7.5 3 12.5 / 12.5 12.8 11.0 / 11.0 11.0
174761**
174559
174763* 15 11 3 19.3 / 19.3 19.7 17.0 / 17.0 16.9
174764**
174562
174766* 20 15 3 25 / 25 25.4 22 / 22 21.5
174767**
174564
25 18.5 3 31 / 31 31.2 27 / 27 26.9
174769*
174566
30 22 3 36 / 36 37.1 32 / 32 31.9
174597*
174599
40 30 3 47 / 47 47.5 41 / 41 40.8
174512*
174594
50 37 3 59 / 59 60.3 52 / 52 51.8
174510*
174573
60 45 3 71 / 71 72.5 62 / 62 61.7
174575*
NOTE See Section 8.0 for recommended fuse type.
* = NEMA 4/12 or 12 ENCLOSURE
** = NEMA 4X ENCLOSURE
OTHERS ARE NEMA 1 ENCLOSURE
