LEGRAND DAKER DK Plus 3 101 73 - 7 Technical Specifications

68
7 Technical specifications
3 101 73 3 101 74
General characteristics
Nominal power (VA) 5000 6000
Active Power (W) 5000 6000
Technology on-line, double conversion, VFI-SS-111
Waveform sinusoidal
Bypass
internal automatic bypass
external maintenance bypass (optional)
Transfer time AC to DC 0 ms
Input characteristics
Input connection Terminal strips
Rated input voltage 230 V
Range of input voltage from 176 V to 280 V at full load
Rated input frequency 50 / 60 Hz ± 5 %
Maximum input current 27.5 A
33 A
Total harmonic distortion
of the input current
THDi < 3%
Input power factor ≥ 0.99 (with full linear load)
Number of input phases Single-phase
Output characteristics
Outlets
(8) 10A,
IEC 320-C13
+
(2) 16A
IEC 320-C19
+
terminal strips
Rated output voltage
230 V ± 1%
adjustable to 200/208/220/230/240 V
Rated output frequency 50 / 60 Hz ± 0,1%
Crest factor 3:1
