23
DMX
3
10.1 Installation des appareils DMX
3
- version fixe
DMX
3
2500. Détails de montage (pour la version 42kA également).
115
115
419
419
66
300
A
A
358
215
A
A
273
354
132108
A A
3P 4P
354
132
350
419
408
A
A
A
115
115
480
538
419
A
66
A A
3P 4P
JEU DE BARRES JEU DE BARRES
A = Point de
fixation sur
la platine de
l’armoire
