89
DMX
3
Inserted/test/draw-out contacts
Technical features
Rated operating voltage Vn (Va.c.): 250V 16A
(Vd.c.): 250V 0,3A
Module programmable output
Technical features
Case: 9 modules
Input supply: 50– 60 Hz; 24 Va.c. +/- 10%; 24 Vd.c. +/- 10%
Contact rated current:
AC 250V 8A
DC 30V - 8A; 110V - 0,3A; 220V - 0,12A
Operating temperature: (-10) – (+55) °C
External auxiliary supply
Technical features
Case: 2 modules
Input supply : 50– 60 Hz; 24 Va.c. +/- 10%; 24 Vd.c. +/- 10%
Input power supply (W/VA) ≥5
Operating temperature: (-10) – (+55) °C
N°1 module is suitable to supply no more than n°1 MP6 or up to n°4 MP4 protection unit.
