10.2 Door cut-out for fixed version
DMX
3
2500-4000-6300. Mounting details.
0÷50mm
ø4 (x10)
358
110124
13.5
3.5
3.5
4
4
284
9
3.5
4
9
4
3.5
11
13.5
110124
Not necessary with
XL
3
-4000 front panel
CORNER OF
THE BREAKER
PANEL DOOR
Thickness of the panel:
MIN 1.2mm -
MAX 2.5mm
* also for 42 kA version
*DMX
3
2500 = 11,5
DMX
3
4000 = 56
DMX
3
6300 = 186
