30
DMX
3
10.4 Découpe et perçage du plastron pour la version débrochable
DMX
3
2500-4000-6300. Détails de montage.
49,5
ø4 (x10)
358
110124
13.5
3.5
3.5
4
4
284
9
3.5
4
9
4
3.5
62
13.5
110124
ANGLE DE
L’APPAREIL
PLASTRON
Pas nécessaire avec
les plastrons XL
3
-4000
Épaisseur du plastron:
MIN 1.2mm -
MAX 2.5mm
distance minimum
*pour la version 42 kA
également
* DMX
3
2500 = 16,5
DMX
3
4000 = 66
DMX
3
6300 = 196
