46
DMX
3
"X" max (mm)
"X" max (mm)
Installation des prises arrières, disponibles comme accessoires.
Les supports
de barres
doivent être en
matériaux isolant
et correctement
dimensionnés
pour ne pas
compromettre les
performances en
présence d’un
éventuel court-
circuit.
DMX
3
2500 = 25 Nm
DMX
3
4000 = 36 Nm
DMX
3
6300 = 36 Nm
Icc (kA) ≤ 42 ≤ 50 ≤ 65 ≤ 100
“X” max (mm) 350 300 250 150
